16 Solid-state Multi-functional Timer H3CR-A
H3CR-A8E
Note: 1. The minimum power-opening time (“Rt”) is 0.1 s.
2. The letter “t” in the timing charts stands for the set time and “t–a” means that the period is less than the time set.
Operating
mode
Timing chart
A:
ON-delay
B
2
:
Flicker ON
start
E:
Interval
J:
One-shot out-
put
t
Power
Power indicator
Power
Output
Basic operation
Output relay
(NC)
Output relay
(NO) (output
indicator)
Instantaneous
output relay (NC)
Instantaneous
output relay (NO)
t ttt
Power
Power indicator
Power
Output
Basic operation
Output relay
(NC)
Output relay
(NO) (output
indicator)
Instantaneous
output relay (NC)
Instantaneous
output relay (NO)
t
Power
Output
Basic operation
Power
Power indicator
Output relay
(NC)
Output relay
(NO) (output
indicator)
Instantaneous
output relay (NC)
Instantaneous
output relay (NO)
t
Power
Power indicator
Power
Output
Basic operation
(Fixed) (Fixed)
Output relay
(NC)
Output relay
(NO) (output
indicator)
Instantaneous
output relay (NC)
Instantaneous
output relay (NO)
1±0.6 s
(Fixed)

Omron H3CR Specifications

General

Output Type	Relay
Time Range	0.05 seconds to 300 hours
Contact Form	SPDT
Number of Pins	8
Operating Temperature	-10°C to 55°C
Storage Temperature	-25°C to 65°C
Operating Voltage	12-240V AC/DC
