Omron H3CR User Manual

Solid-state Twin Timers H3CR-F 29
Dimensions
Note: All units are in millimeters unless otherwise indicated.
66.6
0.7
17.4
52.3
6
5.7
R1.3
44.8 × 44.8
48
48
66.6
0.7
17.4
52.3
6
5.7
R1.3
44.8 × 44.8
48
48
37 dia.
14 dia.
37 dia.
14 dia.
11 pins
8 pins
H3CR-F
H3CR-FN
H3CR-F-300
H3CR-FN-300
H3CR-F8
H3CR-F8N
H3CR-F8-300
H3CR-F8N-300
103.2* 100.9
2.3
*
92.3* 90.0
2.3
*
80
17.4
17.4
75
81.5
81.5
*These dimensions vary with the kind of DIN track (reference value).
Y92F-30
P3GA-11
Y92F-30
P3G-08
Dimensions with Front Connecting Socket
P2CF-08-@/P2CF-11-@
H3CR-F
H3CR-FN
P2CF-11
P2CF-11-E
H3CR-F8
H3CR-F8N
P2CF-08
P2CF-08-E
Dimensions with Back Connecting Socket
P3G-08/P3GA-11
H3CR-F
H3CR-FN
H3CR-F8
H3CR-F8N
(When
Y92A-48G
mounted)
(When
Y92A-48G
mounted)

Omron H3CR Specifications

General

Output Type	Relay
Time Range	0.05 seconds to 300 hours
Contact Form	SPDT
Number of Pins	8
Operating Temperature	-10°C to 55°C
Storage Temperature	-25°C to 65°C
Operating Voltage	12-240V AC/DC
