Product discontinuation
Model H5CN
Recommended replacement
Model H5CN
H5CN-XCNM DC24 / H5CN-XDNM DC24
Connect the timer so that the required supply
voltage can be applied across terminals
②and
⑦. (Make sure that the polarity of the DC power
supply is correct.)
H5CN-XCNM AC100-240 / H5CN-XDNM AC100-240
Connect the timer so that the required supply voltage can
be applied across terminals ②and ⑦.
H5CN-YCNM AC100-240
・Connection of Power Supply
H5CN-YCN AC100-240
Use the socket P2CF-08(-E) and P3G-08 PIN type is
changed to 8-pin
・Connection of Power Supply
H5CN-YCNM AC100-240
・Connection of Load Circuit
H5CN-YCN AC100-240
・Connection of Load Circuit
・Connection of Gate Input
・Connection of Gate Input
