Omron H7AN - Wiring Diagrams

3
Wiring Diagrams
Product discontinuation
Model H7AN / H7CN
Recommended replacement
Model H7AN / H7CN
H7AN-E4D DC12-24 / H7AN-E4DM DC12-24 /
H7AN-ET4 DC12-24 /H7AN-ET4M DC12-24 /
H7AN-R6D DC12-24 / H7AN-RT6 DC12-24 /
H7AN-RT8 DC12-24 / H7AN-T4 DC12-24 /
H7AN-W4D DC12-24 / H7AN-WE4D DC12-24 /
H7AN-WE4DM DC12-24
・Connection of Power Supply
Polarity for DC powersupply
Terminal 1→（－） Terminal 2→（＋）
H7AN-E4D AC100-240 / H7AN-E4DM AC100-240 /
H7AN-ET4M AC100-240 / H7AN-R6D AC100-240 /
H7AN-RT6 AC100-240 / H7AN-T4 AC100-240 /
H7AN-W4D AC100-240 / H7AN-WE4D AC100-240 /
H7AN-WE4DM AC100-240
・Connection of Power Supply
H7CN-BHN DC12-48
・ Connection of Power Supply
H7CN-BHN AC100-240
・Connection of Power Supply
H7CN-YHNS AC100-240
・ Connection of Power Supply
H7CN-YHNS DC12-48
・Connection of Power Supply
DC power supply input
AC power supply input
