H7CX-A@-N
17
Counter
(9999 × 1000 times)(0 × 1000 times)
(OFST)(ABS)
(KP-1) (KP-2) (KP-3) (KP-4) (KP-5) (KP-6) (KP-7)
(9999 × 1000 times)(0 × 1000 times)
(9999 × 1000 times)(0 × 1000 times)
99990
99990
99990
(9999)(1)
99991
(9999)(1)
99991
(9999)(1)
99991
ofstabs
kp-1 kp-2 kp-3 kp-4 kp-5
kp-6 kp-7
(ON)(OFF)
onoff
*8
Note: 1 to 999999 for 6-digit models
*8 Set each digit using the individual U (D) Keys.
Note: The monitor value is only displayed. It cannot be set.
Forecast
setting
upper limit
(PL-H)
Key protect
level
(KYPT)
From previous
page
To previous
page
Output ON
count alarm set
value/monitor
value
• Make the absolute value setting and forecast setting using the U (D) Keys.
• Set each digit using the individual U (D) Keys.
• Set each digit using the individual U (D) Keys.
• Set the key protect level using the U (D) Keys.
Procedure for Models Other than “-@W@” Models
Output
ON count
alarm set
value
Output
ON count
monitor
value
Output 1
(OUT1) ON
count alarm
set value
Function Setting Mode
Absolute value
setting/forecast
value setting
(SETM)
Set value
upper limit
(SL-H)
Note: 1 to 999999 for 6-digit models.
Note: 1 to 999999 for 6-digit models.
Note: Displayed only when the output mode is set to bcnt.
• Set each digit using the individual U (D) Keys.
Procedure for “-@W@” Models
Note: The monitor value is only displayed. It cannot be set.
Note: The monitor value is only displayed. It cannot be set.
Output 2
(OUT2) ON
count alarm
set value
Output 1
(OUT1) ON
count monitor
value
Output 2
(OUT2) ON
count monitor
value
Batch count
upper limit
(BL-H)
Note: Displayed only when the configuration selection mode is set to the 2-stage function 2cnt.
Note: Displayed only when the configuration selection mode is set to the 2-stage function 2cnt and a forecast value is set.
Output
allocation
change
Note: Displayed only for "-AU@" models.
off: Output 1 = 12, 13, Output 2 = 3, 4, 5 on: Output 1 = 3, 4, 5, Output 2 = 12, 13
The numbers are the terminals numbers.
To Next Page
