Omron H7CX- -N Series User Manual

H7CX-A@-N
29
Tachometer
(Enabled)(Disabled)
(Red) (Green) (Orange) (Red-green) (Green-red) (Red-orange) (Orange-red) (Green-orange) (Orange-green)
(PNP input)(NPN input)
(19.99 s)(0.00 s)
99990
99990
(99999)(0)
999990
(999999)
999999
onoff
grnred org r-g g-r r-o o-r g-o o-g
npn pnp
19.990.00
(9999 × 1000 times)(0 × 1000 times)
(9999 × 1000 times)(0 × 1000 times)
*2 Set each digit using the individual U Keys.
From previous
page
To previous
page
• Set the NPN/PNP input mode using the U Key.
Output 1
(OUT1) ON
count alarm
set value
Output 2
(OUT2) ON
count alarm
set value
Output 1
(OUT1) ON
count monitor
value
Function Setting Mode
NPN/PNP
input mode
(IMOD)
Display
color
(COLR)
Note: The monitor value is only
displayed. It cannot be set.
Output 2
(OUT2) ON
count
monitor value
Peak/bottom
hold enabled
(DHLD)
Output
hysteresis
(HYS)
Output OFF
delay
(OFFD)
Set value
upper limit
(SL-H)
• Set the display color using the U Key.
• Enable or disable the peak/bottom hold using the U Key.
• Set the output hysteresis using the U Key.
Note: The measurement value after prescaling is set.
• Set each digit using the individual U Key.
• Set each digit using the individual U Key.
Note: The monitor value is only
displayed. It cannot be set.
(1)
1
(Pulse width
measurement)
(Pulse cycle
measurement)
(s)(Hz)
(Cont (10 ms min.)) ( 200 ms)
(KP-1) (KP-2) (KP-3) (KP-4) (KP-5) (KP-6) (KP-7)
phas
shz
cont200ms
kp-1 kp-2 kp-3 kp-4 kp-5 kp-6 kp-7
*2
Key protect
level
(KYPT)
Pulse cycle
measurement/
pulse width
measurement
(CALM)
Display unit
(UNIT)
Measurement
interval
(INTV)
Output ON
count alarm set
value/monitor
value
• Set the key protect level using the U Key.
• Set pulse cycle measurement or pulse width measurement using the U Key.
• Set the display unit using the U Key.
Note: Displayed only when pulse cycle measurement is
used.
• Set each digit using the individual U Key.
Note: Displayed only if the measurement speed is 10 kHz
when pulse cycle measurement is used.
(ON)(OFF)
onoff
Output
allocation
change
Note: Displayed only for "-AU@" models.
off: Output 1 = 12, 13, Output 2 = 3, 4, 5
on: Output 1 = 3, 4, 5, Output 2 = 12, 13
The numbers are the terminals numbers.

Omron H7CX- -N Series Specifications

General

Input Type	Contact input
Output Type	Relay
Counting Mode	Count up/down
Reset Method	Manual or external signal
Operating Temperature	-10 to 55°C (with no icing or condensation)
Storage Temperature	-25 to 65°C (with no icing or condensation)
Mounting	Panel mount
Supply Voltage	100-240V AC
