Omron H7CX- -N Series User Manual

4
H7CX-@-N
Accessories (Order Separately)
Front Panels (Replacement Part)
Note: 1. You can change the color of the Front Panel when mounting the Counter. The Counter is shipped with a black (N1.5) Front Panel.
2. "COUNTER" is printed on the front of Replacement Front Panels.
Soft Cover
Hard Cover
Flush Mounting Adapter
Waterproof Packing
Connection Sockets
Terminal Covers for P3GA-11 Back-connecting Socket
Model Color Applicable Counters Page
Y92P-CXC4G Light gray (5Y7/1) 4-digit Counter
12
Y92P-CXC4S White (5Y9.2/0.5)
Y92P-CXC4B Black (N1.5)
Y92P-CXC6G Light gray (5Y7/1) 6-digit Counter
Y92P-CXC6S White (5Y9.2/0.5)
Y92P-CXC6B Black (N1.5)
Model Remarks Page
Y92A-48F1 --- 12
Model Remarks Page
Y92A-48 --- 12
Model Remarks Page
Y92F-30
Included with models with screw
terminals.
12
Y92F-45
Use this Adapter to install the Counter/
Tachometer in a cutout previously made
for a DIN 72 × 72 mm device (panel
cutout: 68 × 68 mm).
Model Remarks Page
Y92S-29
Included with models with screw
terminals.
12
Model Classification
Connectable
Counter/
Tachometers
Remarks Page
P2CF-11 Front-connecting Socket
H7CX-@11@-N
---
13
P2CF-11-E
Front-connecting Socket (Finger-safe
Type)
Round crimp terminals cannot be used on
Finger-safe Sockets.
Use forked crimp terminals.
P3GA-11 Back-connecting Sockets
A Y92A-48G Terminal Cover can be used
with the Socket to create a finger-safe
construction.
Model Remarks Page
Y92A-48G --- 13

Omron H7CX- -N Series Specifications

General

Input Type	Contact input
Output Type	Relay
Counting Mode	Count up/down
Reset Method	Manual or external signal
Operating Temperature	-10 to 55°C (with no icing or condensation)
Storage Temperature	-25 to 65°C (with no icing or condensation)
Mounting	Panel mount
Supply Voltage	100-240V AC
