6 Cam Positioner H8PS
Connections
■ Terminal Arrangement
H8PS-8@ (8-output Models) H8PS-16@/-32@ (16-/32-output Models)
Encoder
12345678
9 10111213
24 VD
C
+ −
Alignment markings
(Rear view)
Pulse output
RUN output
Not used
C
am 1
C
am 2
C
am 3
C
am 4
C
am 5
C
am 6
C
am 7
C
am 8
NPN Output,
Flush Mounting
H8PS-8@
Encoder
678910111213
12345
Alignment markings
(Rear view)
24 VDC
+ −
Bank 1 Bank 2
Bank 4
Origin
Start
Not used
Not used
Not used
Pulse output
RUN output
COM
NPN Output,
Flush Mounting
H8PS-16@/-32@
12345678
910111213
24 VDC
+ −
Encoder
Alignment markings
(Front view)
Pulse output
RUN output
Not used
C
am 1
C
am 2
C
am 3
C
am 4
C
am 5
C
am 6
C
am 7
C
am 8
NPN Output,
Surface Mounting
H8PS-8@F
678910111213
12345
24 VDC
+ −
Encoder
Alignment markings
(Front view)
Bank 1 Bank 2
Bank 4
Origin
Start
Not used
Not used
Not used
Pulse output
RUN output
COM
NPN Output,
Surface Mounting
H8PS-16@F/-32@F
12345678
9 10111213
24 VDC
+ −
Encoder
Alignment markings
(Rear view)
Pulse output
RUN output
Cam 1 Cam 2 Cam 3 Cam 4 Cam 5 Cam 6 Cam 7 Cam 8
Vs (See note.)
PNP Output,
Flush Mounting
H8PS-8@P
Note: The VS terminal
is not internally
connected to the
positive (+) power
supply terminal.
6 7 8 9 10111213
12345
24 VDC
+ −
Encoder
Alignment markings
(Rear view)
Bank 1 Bank 2
Bank 4
Origin
Start
Not used
Not used
Vs (See note.)
Pulse output
RUN output
COM
PNP Output,
Flush Mounting
H8PS-16@P/-32@P
Note: The VS terminal
is not internally
connected to
the positive (+)
power supply
terminal.
12345678
9 10111213
24 VDC
+ −
Encoder
Alignment markings
(Front view)
Pulse output
RUN output
Cam 1 Cam 2 Cam 3 Cam 4 Cam 5 Cam 6 Cam 7 Cam 8
Vs (See note.)
PNP Output,
Surface Mounting
H8PS-8@FP
Note: The VS terminal
is not internally
connected to the
positive (+) power
supply terminal.
6 7 8 9 10111213
12345
24 VDC
+ −
Encoder
Alignment markings
(Front view)
Bank 1 Bank 2
Bank 4
Origin
Start
Not used
Not used
Vs (See note.)
Pulse output
RUN output
COM
PNP Output,
Surface Mounting
H8PS-16@FP/-32@FP
Note: The VS terminal
is not internally
connected to the
positive (+) power
supply terminal.
