10-9
DeviceNet Connection Hardware Section 8-3
Additional Informa-
tion for DeviceNet
T- b r a n c h Ta p s
One-branch Taps
Three-branch Taps
Shielded T-branch Connectors
One-branch Power Supply Tap
Model Specifications Manufacturer
DCN1-1C Includes three XW4B-05C1-H1-D parallel connectors with screws
(When used on a trunk line, one branch line can be connected.)
Connector insertion direction: Horizontal
A Terminating Resistor (included as standard) can be connected.
OMRON
DCN1-2C Includes three XW4B-05C1-H1-D parallel connectors with screws
(When used on a trunk line, one branch line can be connected.)
Connector insertion direction: Vertical
A Terminating Resistor (included as standard) can be connected.
OMRON
DCN1-2R Includes three XW4B-05C1-VIR-D orthogonal connectors with screws
(When used on a trunk line, one branch line can be connected.)
Connector insertion direction: Vertical
A Terminating Resistor (included as standard) can be connected.
OMRON
Model Specifications Manufacturer
DCN1-3C Includes five XW4B-05C1-H1-D parallel connectors with screws
(When used on a trunk line, three branch lines can be connected.)
Connector insertion direction: Horizontal
A Terminating Resistor (included as standard) can be connected.
OMRON
DCN1-4C Includes five XW4B-05C1-H1-D parallel connectors with screws
(When used on a trunk line, three branch lines can be connected.)
Connector insertion direction: Vertical
A Terminating Resistor (included as standard) can be connected.
OMRON
DCN1-4R Includes five XW4B-05C1-VIR-D orthogonal connectors with screws
(When used on a trunk line, three branch lines can be connected.)
Connector insertion direction: Vertical
A Terminating Resistor (included as standard) can be connected.
OMRON
Model Specifications Manufacturer
DCN2-1 One-branch shielded T-branch connectors, three micro-size (M12) connectors OMRON
DCN3-11 One-branch shielded T-branch connectors, three mini-size connectors
DCN3-12 One-branch shielded T-branch connectors, two mini-size connectors and one
micro-size (M12) connector
Model Specifications Manufacturer
DCN1-1P One-branch tap for power supply. Use this tap when connecting a communica-
tions power supply.
Includes two XW4B-05C1-H1-D parallel connectors with screws and two fuses
as standard.
A Terminating Resistor (included as standard) can be connected.
OMRON
