CHARACTERISTICS
Input signal DC voltage/current, AC voltage/current
A/D conversion method Double integral method
Sampling period 50 Hz: 12.5 times/s; 60 Hz: 15 times/s (selectable)
Display refresh period Sampling period (sampling times multiplied by number of averaging times if simple average
processing is selected.)
Max. displayed digits 5 digits (--19999 to 99999)
Display 7-segment LED
Polarity display “--” is displayed automatically with a negative input signal.
Zero display Leading zeros are not displayed.
Scaling function Programmable with front-panel key inputs (range of display: --19999 to 99999). The decimal
point position can be set freely.
HOLD function Maximum hold (maximum data)
Minimum hold (minimum data)
External controls HOLD: Process value held
RESET: Maximum/Minimum data reset
ZERO: Forced zero
Comparative output hysteresis setting Programmable with front-panel key inputs (1 to 9999).
Other functions Variable linear output range (for models with linear outputs only)
Remote/Local processing (available for communications output models only)
Maximum/Minimum value data reset with front panel keys
Forced-zero set with front panel keys
Averaging processing function (simple or moving average)
Startup compensation time (0.0 to 99.9 s)
Comparative output pattern selection
Security
Field calibration
Output configuration Relay contact output (5 outputs)
Transistor output (NPN and PNP open collector), BCD (NPN open collector)
Parallel BCD (NPN open collector) + transistor output (NPN open collector)
Linear output (4 to 20 mA, 1 to 5 V) + transistor output (NPN open collector)
Communication functions (RS-232C, RS-485, RS-422)
Communication functions (RS-232C, RS-485, RS-422) + transistor output (NPN open
collector)
Delay in comparative outputs
(transistor output)
DC input: 200 ms max.
AC input: 400 ms max.
Enclosure ratings
Front panel NEMA4 for indoor use (equivalent to IP66)
g
Rear case IEC standard IP20
Terminals IEC standard IP00
Memory protection Non-volatile memory (EEPROM) possible to rewrite 100,000 times
