K3NX
K3NX
9
VA: AC Voltage Input AA: AC Current Input
1 2 3 4
0 to 1.9999 V
ANALOG
COM.
0 to 19.999 V
0 to 199.99 V
0 to 400.0 V
1 2 3 4
0 to 199.99 mA
0 to 1.9999 A
0 to 10.000 A
ANALOG
COM.
0 to 19.999 mA
3
OUTPUT OPERATION TIMING IN RUN MODE (RELAY OR TRANSISTOR OUTPUTS)
The following timing chart is for a 5-comparative output board when the standard output pattern is selected.
Display
HH set value
H set value
L set value
LL set value
HH comparative output
H comparative output
PASS output
L comparative output
LL comparative output
Display value
Hysteresis
HYS
HYS
HYS
HYS
Note: The hysteresis value set in setting mode will be applied to all set values.
