Omron NB-series Service Guide

12
■Mounting dimensions
Discontinued Products
NB□□-TW□□B
Recommended Replacements
NB□□-TW□□B -V1
NB3Q-TW□□B
Panel cutout
119.0(+0.5/-0) (W), 93.0(+0.5/-0) (H)
Panel thickness: 1.6 to 4.8mm
NB3Q-TW□□B -V1
Panel cutout
119.0(+0.5/-0) (W), 93.0(+0.5/-0) (H)
Panel thickness: 1.6 to 4.8mm
NB5Q-TW□□B
Panel cutout
172.4(+0.5/-0) (W), 131.0(+0.5/-0) (H)
Panel thickness: 1.6 to 4.8mm
NB5Q-TW□□B -V1
Panel cutout
172.4(+0.5/-0) (W), 131.0(+0.5/-0) (H)
Panel thickness: 1.6 to 4.8mm
NB7W-TW□□B
Panel cutout
191.0(+0.5/-0) (W), 137.0(+0.5/-0) (H)
Panel thickness: 1.6 to 4.8mm
NB7W-TW□□B -V1
Panel cutout
191.0(+0.5/-0) (W), 137.0(+0.5/-0) (H)
Panel thickness: 1.6 to 4.8mm
NB10W-TW□□B
Panel cutout
258.0(+0.5/-0) (W), 200.0(+0.5/-0) (H)
Panel thickness: 1.6 to 4.8mm
NB10W-TW□□B -V1
Panel cutout
258.0(+0.5/-0) (W), 200.0(+0.5/-0) (H)
Panel thickness: 1.6 to 4.8mm
■Dimensions
Discontinued Products
NB□□-TW□□B
Recommended Replacements
NB□□-TW□□B -V1
NB3Q-TW□□B
129.8×103.8×52.8 (mm)
NB3Q-TW□□B -V1
129.8×103.8×52.8 (mm)
NB5Q-TW□□B
184.0×142.0×46.0 (mm)
NB5Q-TW□□B -V1
184.0×142.0×46.0 (mm)
NB7W-TW□□B
202.0×148.0×46.0 (mm)
NB7W-TW□□B -V1
202.0×148.0×46.0 (mm)
NB10W-TW□□B
268.8×210.8×54.0 (mm)
NB10W-TW□□B -V1
268.8×210.8×54.0 (mm)
