４-４ Installing NB-V1
4-4-1 Installing the NB-V1 to the operation panel
Mount the NB-V1 to the operation panel using panel mounting brackets and a screwdriver.
4-4-2 Wiring the cables
Connect all the cables for the NB-V1.
4-4-3 Installing the storage devices (If necessary)
Install the USB memory.
