Appendix-1 Transferring project data by
using a media device
Even if NB-Designer is not available, project files can be transferred by using a media device.
**NB-Designer is required for screen conversion.
4-2-2 Uploading the project from the existing NB -> Go to A-1-1
4-5-2 Downloading the project to the NB-V1 -> Go to A-1-2
These functions are described in the following sections.
A-1-1 Uploading by using a storage media
1. Insert the USB memory device
to use for the upload into the
computer.
2. Enter the System Setting Mode
following the procedures below.
(1) Set both the DIP switches
SW1 and SW2 on the back side
to ON.
(2) Press the Reset switch,
restart the NB Unit, and then it
enters into the System Setting
Mode.
3. Touch the USBHMI button.
*Uploads the user project file
required by the PT operation to
the USB memory.
To Next Page
