1-3
1 NB Overview
NB-series Programmable Terminals Startup Guide Manual(V109)
1-2 Part Names and Functions
1
1-2 Part Names and Functions
This section describes the names and functions of each part of the NB Unit.
z NB3Q-TW00B/NB3Q-TW01B model
Front view
Back view
Precautions for Safe Use
Confirm the safety of the system before turning ON or OFF the power supply, or pressing the
reset button.
Power Indicator Dis
p
la
y
: NB-TW01B only

Related product manuals
