3 Connecting to Mitsubishi PLCs
3-34
NB-series Programmable Terminals Host Connection Manual (V108)
Mitsubishi QJ71E71 Ethernet (TCP Slave) Driver
Counter Value ------ CN 0-32767 DDDDD
Index Register ------ Z 0-19 DD
File Register ------ R 0-32767 DDDDD
File Register
(Block switching is not
necessary)
------ ZR 0-4849663 DDDDDDD
Special Link Resister ------ SB 0-7FF0 HHHH
Link Resister ------ B 0-EFF0 HHHH
Input ------ X 0-3FF0 HHHH
Output ------ Y 0-3FF0 HHHH
Device Bit Address Word Address Format Notes
Input Relay X 0-2000 ------ HHHH
Output Relay Y 0-2000 ------ HHHH
Internal Relay M 0-32768 ------ DDDDD
Special Internal Relay SM 0-2048 ------ DDDD
Latch Relay L 0-32768 ------ DDDDD
Annunciator F 0-32768 ------ DDDDD
Edge Relay V 0-32768 ------ DDDDD
Link Relay B 0-8000 ------ HHHH
Timer Contact TS 0-23088 ------ DDDDD
Timer Coil TC 0-23088 ------ DDDDD
Accumulated Timer
(contact)
SS 0-23088 ------ DDDDD
Accumulated Timer
(coil)
SC 0-23088 ------ DDDDD
Counter Contact CS 0-23088 ------ DDDDD
Counter Coil CC 0-23088 ------ DDDDD
Special Link Relay SB 0-8000 ------ HHHH
Step Relay S 0-8192 ------ DDDD
Data Register ------ D 0-25984 DDDDD
Special Data Register ------ SD 0-2048 DDDD
Link Register ------ W 0- 2920 HHHH
Special Link Register ------ SW 0-800 HHH
Timer Value ------ TN 0-23088 DDDDD
Accumulated Timer
(present value (PV))
------ SN 0-23088 DDDDD
Counter Value ------ CN 0-23088 DDDDD
File Register ------ R 0-32768 DDDDD
File Register
(Block switching is not
necessary)
------ ZR 0-1042432 DDDDDDD
Device Bit Address Word Address Format Notes
