Omron NB7W-TW**B series - Serial Port Communication Parameters and Cable Fabrication

10-3
10 Connecting to PLC of GE Fanuc Automation Inc.
NB-series Programmable Terminals Host Connection Manual (V108)
10-2 Serial Port Communication
Parameters and Cable
10
10-2 Serial Port Communication
Parameters and Cable Fabrication
Series CPU Link Module COMM Type Parameter Cable
GE Fanuc
Series 90-30
IC693CPU374 RS422 on the
CPU unit
RS232 Refer to Section 10-3 Self-made cable
required
RS422
IC693CMM311 RS232
RS422
VersaMax
Series
CPU001/002/005 RS232 on port1 RS232
RS422 on port2 RS422
VersaMax
Micro &
Nano Series
IC200UAL004/005/006
IC200UDD110/120/212
IC200UDR005/006/010
IC200UAA007
IC200UAR028
RS232 on port1 RS232
RS422on port2 RS422
