2-31
2 Installing the NB Unit and Connecting Peripheral Devices
NB-series Programmable Terminals Setup Manual(V107)
2-5 FINS/UDP Communication Connection
2
2-5-3 Host Types and Settings of Ethernet Unit
Units that are used for Ethernet communications vary according to the type and series of OMRON
PLC used.
When connecting an Ethernet Unit, check the series and type of the PLC that it will be connected to
and the model of the Unit that is mounted to the PLC.
NB-series PTs and the following Controllers can be connected with Ethernet units.
For details on the hosts that can be connected to NB-series PTs via the Ethernet, refer to A-5 List of
Models.
Host Settings
The types of hosts that can be connected to NB-series PTs with the Ethernet and the host settings
are as follows. The following settings must be set at the host.
Note 1 The max total number of registered nodes by NB-Designer in the network is 33, at least 1 NB-series PT
and 1 host included.
2 If there is CP1E PLC in the actual network architecture, the Network No. must be set to 0.
3 The Node ID of 0 is equivalent to that of 1 (default).
2-5-3 Host Types and Settings of Ethernet Unit
Series name Using the built-in board Using an Ethernet Unit Ethernet Unit
CS Series — CS1G/H-CPU(-V1) CS1W-ETN21
CS1G/H-CPUH
CS1D-CPUH CS1W-ETN21
CJ Series
—
CJ1G/H-CPUH CJ1W-ETN21
CJ1M-CPU(-ETN)
CJ1M-CPU-ETN — —
— CJ2H-CPU(-EIP) CJ1W-ETN21
CJ2M-CPU
CP1H Series — CP1H-Y CJ1W-ETN21
CP1W-CIF41
CP1H-XA
CP1H-X
CP1L Series — CP1L-L14/20 CP1W-CIF41
CP1L-M30/40/60
CP1L-EL20 — —
CP1L-EM30/40
CP1E Series — CP1E-N30 CP1W-CIF41
CP1E-N40
CP1E-N60
CP1E-NA20
Item Host Settings
Number of nodes 33 (See note 1)
Network number 0 to 127 (See note 2)
UDP port number 1024 to 65535, default is 9600.
IP address 0.0.0.0 to 255.255.255.255
Subnet mask 0.0.0.0 to 255.255.255.255
Default gateway 0.0.0.0 to 255.255.255.255
Node number 0 to 254 (See note 3)
