Omron NE-C801 User Manual

12
3. Preparing the nebulizer for use
6. Attach the desired inhalation attachment, as described below.
Attaching the mouthpiece
1) Attach the cap to the inhalation air inlet.
2) Attach the mouthpiece to the inhalation top.
Attaching the nosepiece (optional)
1) Attach the cap to the inhalation air inlet.
2) Attach the nosepiece to the inhalation top.
Attaching the adult mask (PVC)
Attach the adult mask to the inhalation top.
Note: If the amount of aerosol is too great,
attach the cap.
Attaching the child mask (PVC)
1) Attach the cap to the inhalation air inlet.
2) Attach the child mask to the inhalation top.
Note: If the amount of aerosol is too small, it is
not necessary to place the cap.
NE-C801S-ID_B_M.book Page 12 Friday, December 16, 2011 11:46 AM

Omron NE-C801 Specifications

General

Type	Compressor Nebulizer
Nebulization Rate	Approximately 0.3 ml/min
Power Supply	AC 50/60Hz
Weight	Approx. 270 g (without accessories)
Residual Volume	Approx. 0.7 ml
Operating Conditions	Temperature: 10-40°C, Humidity: 30 to 85% RH
Particle Size	MMAD approximately 3.0 µm
Dimensions	Approx. 142 mm (W) × 72 mm (H) × 98 mm (D)
