Omron NE-C803 User Manual

10
5.
Make sure that the vaporizer head is
securely attached to the inhalation top.
Note:
The sizes of the left- and right-hand
attached parts of the vaporizer head are
not the same. If the vaporizer head is not
attached in the correct orientation, it will not
nebulize correctly.
6.
Put the inhalation top back inside the
medication tank.
1) Align the protrusion on the inhalation
top with the indent on the medication
tank, as shown.
2) Rotate the inhalation top clockwise
until the arrow mark on it and the
alignment mark on the medication
tank are aligned, and they click in
place.
Arrow mark
Alignment
mark
Small
Large

Omron NE-C803 Specifications

General

Type	Compressor Nebulizer
Nebulization Rate	0.3 ml/min
Medication Capacity	10 ml
Particle Size	MMAD approximately 3 μm
Noise Level	45 dB
Power Source	AC Adapter
Weight	Approximately 180 g (compressor only)
Dimensions	Approx. 85 (W) × 43 (H) × 115 (D) mm
Airflow	8 L/min
Power Consumption	9W
Power Supply	AC Adapter
