Omron NJ Series Troubleshooting Manual

3 Error Tables
3-56
NJ-series Troubleshooting Manual (W503)
54320000 hex Transition
Mode Selec-
tion Out of
Range
The parameter
specified for the
TransitionMode
input variable to a
motion control
instruction is out of
range.
• Instruction input parameter
exceeded the valid range of the
input variable.
• _mcAborting or _mcBuffered
was specified for BufferMode
and
_mcTMCornerSuperimposed
was specified for Transition-
Mode.
S NJ-series
Motion Con-
trol Instruc-
tions
Reference
Manual (Cat.
No. W508)
54330000 hex Continue
Method
Selection Out
of Range
The value of the
reserved input vari-
able Continuous to
a motion control
instruction
changed.
• The value of the reserved input
variable Continuous changed.
S Same as
above.
54340000 hex Combine
Mode Selec-
tion Out of
Range
The parameter
specified for the
CombineMode
input variable to a
motion control
instruction is out of
range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
54350000 hex Synchroniza-
tion Start
Condition
Selection Out
of Range
The parameter
specified for the
LinkOption input
variable to a motion
control instruction is
out of range.
• Instruction input parameter
exceeded the valid range of the
input variable.
S Same as
above.
54360000 hex Master and
Slave
Defined as
Same Axis
The same axis is
specified for the
Master and Slave
input variables to a
motion control
instruction.
• The parameter is the same for
the Master and Slave input vari-
ables to the instruction.
S Same as
abo
ve.
54
370000 hex Master and
Auxiliary
Defined as
Same Axis
The same axis is
specified for the
Master and Auxil-
iary input variables
to a motion control
instruction.
• The parameter is the same for
the Master and Auxiliary input
variables to the instruction.
S Same as
above.
54380000 hex Master/Slave
Axis Num-
bers Not in
Ascending
Order
The axis numbers
specified for the
Master and Slave
input variables to a
motion control
instruction are not
in ascending order.
• The parameters for the Master
and Slave input variables to the
instruction were not in ascend-
ing order when
_mcLatestCommand was spec-
ified for the ReferenceType
input variable to the instruction.
S Same as
above.
54390000 hex Incorrect
Cam Table
Specification
The parameter
specified for the
CamTable input
variable to a motion
control instruction is
out of range.
• Something other than a cam
data variable was specified for
the CamTable input variable to
the instruction.
S Same as
above.
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info
