3 Error Tables
NJ-series Troubleshooting Manual (W503)
3-1 Errors by Source
3
3-1-7 Errors in Slave Terminals
80200000 hex NX Unit I/O
Communica-
tions Error
A communications
error occurred
between the Com-
munications Cou-
pler Unit and the
NX Unit.
• The NX Unit is not mounted
properly.
• The power cable for the Unit
power supply is disconnected.
Or, the wiring from the Unit
power supply to the NX Units is
incorrect.
• The power cable for the Unit
power supply is broken.
• The voltage of the Unit power
supply is outside the specified
range. Or, the capacity of the
Unit power supply is insuffi-
cient.
• There is a hardware error in the
NX Unit.
SNX-series
Position Inter-
face Units
User’s Manual
(W524)
80210000 hex NX Unit Out-
put Synchro-
nization Error
An output synchro-
nization error
occurred in the NX
Unit.
• The NX Unit is not mounted
properly.
• The Slave Terminal Configura-
tion Information when the
EtherCAT Coupler Unit syn-
chronization settings were
downloaded did not agree with
the actual configuration of the
Slave Terminal.
• There is an NX Unit that cannot
be synchronized to the
specified output
synchronization timing. (This
will not cause an error when the
synchronization setting is made
from the Sysmac Studio.)
S Same as
above.
80240000 hex NX Unit
Clock Not
Synchro-
nized Error
An error occurred in
the clock
information
between the
EtherCAT Coupler
Unit and the NX
Unit.
• There is a hardware error in the
NX Unit.
• There is a hardware error in the
EtherCAT Coupler Unit.
S Same as
above.
80220000 hex NX Message
Communica-
tions Error
An error was
detected in mes-
sage communica-
tions and the
message frame
was discarded.
• The message communications
load is high.
• The communications cable is
disconnected or broken.
This cause does not apply if
attached information 2 is 0 (NX
bus).
• Message communications were
cut off as the result of executing
a synchronization or restora-
tion operation on the Sysmac
Studio or as the result of dis-
connecting an EtherCAT slave.
S Same as
above.
84D00000 hex SSI Commu-
nications
Error
An error occurred in
SSI communica-
tions.
• The SSI data settings do not
agree with the SSI communica-
tions settings
in the connect
ed
device.
• The wiring between the NX Unit
and the connected device is not
correct or disconnected.
• Noise
US Same as
above.
90400000 hex Event Log
Cleared
The event log was
cleared.
• The event log was cleared by
the user.
S Same as
above.
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info
To Next Page
