Omron NJ Series Troubleshooting Manual

3-103
3 Error Tables
NJ-series Troubleshooting Manual (W503)
3-1 Errors by Source
3
3-1-7 Errors in Slave Terminals
74A10000 hex SF_EDM
Error
An error was
detected in execu-
tion of a safety
function block.
Refer to information on the diag-
nostic code that is given for
attached information 1 in the NX-
series Safety Control Unit Instruc-
tions Reference Manual (Cat. No.
Z931)
SNX-series
Safety Control
Unit User’s
Manual (Z930)
74A20000 hex SF_Emergen
cyStop Error
An error was
detected in execu-
tion of a safety
function block.
Refer to information on the diag-
nostic code that is given for
attached information 1 in the NX-
series Safety Control Unit Instruc-
tions Reference Manual (Cat. No.
Z931)
S Same as
above.
74A30000 hex SF_EnableS
witch Error
An error was
detected in execu-
tion of a safety
function block.
Refer to information on the diag-
nostic code that is given for
attached information 1 in the NX-
series Safety Control Unit Instruc-
tions Reference Manual (Cat. No.
Z931)
S Same as
above.
74A40000 hex SF_Equivale
nt Error
An error was
detected in execu-
tion of a safety
function block.
Refer to information on the diag-
nostic code that is given for
attached information 1 in the NX-
series Safety Control Unit Instruc-
tions Reference Manual (Cat. No.
Z931)
S Same as
above.
74A50000 hex SF_ESPE
Error
An error was
detected in execu-
tion of a safety
function block.
Refer to information on the diag-
nostic code that is given for
attached information 1 in the NX-
series Safety Control Unit Instruc-
tions Reference Manual (Cat. No.
Z931)
S Same as
above.
74A60000 hex SF_GuardLo
cking Error
An error was
detected in execu-
tion of a safety
function block..
Refer to information on the diag-
nostic code that is given for
attached information 1 in the NX-
series Safety Control Unit Instruc-
tions Reference Manual (Cat. No.
Z931)
S Same as
above.
74A70000 hex SF_GuardMo
nitoring Error
An error was
detected in execu-
tion of a safety
function block.
Refer to information on the diag-
nostic code that is given for
attached information 1 in the NX-
series Safety Control Unit Instruc-
tions Reference Manual (Cat. No.
Z931)
S
Same as
above.
74A80000 hex SF_ModeSel
ector Error
An error was
detected in execu-
tion of a safety
function block.
Refer to information on the diag-
nostic code that is given for
attached information 1 in the NX-
series Safety Control Unit Instruc-
tions Reference Manual (Cat. No.
Z931)
S Same as
above.
74A90000 hex SF_MutingPa
r Error
An error was
detected in execu-
tion of a safety
function block.
Refer to information on the diag-
nostic code that is given for
attached information 1 in the NX-
series Safety Control Unit Instruc-
tions Reference Manual (Cat. No.
Z931)
S Same as
above.
74AA0000 hex SF_MutingPa
r_2Sensor
Error
An error was
detected in execu-
tion of a safety
function block.
Refer to information on the diag-
nostic code that is given for
attached information 1 in the NX-
series Safety Control Unit Instruc-
tions Reference Manual (Cat. No.
Z931)
S Same as
above.
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info
