3 Error Tables
3-130
NJ-series Troubleshooting Manual (W503)
34850000 hex Mean Value
Processing
Setting Error
There is a mistake
in the setting of the
number of sam-
plings for mean
value processing.
• There is a mistake in the setting
of the number of samplings for
mean value processing.
S CJ-series
Analog I/O
Units Opera-
tion Manual for
NJ-series
CPU Unit (Cat.
No. W490)
34860000 hex Error in Set-
ting of Con-
version Mode
There is a mistake
is the Conversion
Mode setting.
• The specification of the Cyclic
Conversion Mode or Direct
Conversion Mode is not correct.
S Same as
above.
34870000 hex Output Hold
Setting Error
There is a mistake
in the output hold
setting.
• The setting for output status
when conversion stops is incor-
rect.
S Same as
above.
34890000 hex Conversion
Time/Resolu-
tion or Oper-
ation Mode
Setting Error
There is a mistake
in the conversion
time/resolution or
operation mode set-
ting.
• There is a mistake in the con-
version time/resolution or oper-
ation mode setting.
S Same as
above.
348A0000 hex Output Signal
Range Set-
ting Error or
Error In Num-
ber of Out-
puts Used
Setting
There is a mistake
in the output signal
range setting or in
the number of out-
puts setting.
• There is a mistake in the output
signal range setting or in the
number of outputs setting.
S Same as
above.
38010000 hex Scaling Data
Setting
Error/Ratio
Conversion
Use Setting
Error
There is an error in
the scaling data
setting or ratio con-
version use setting.
• The upper or lower limit data for
scaling is outside the setting
range. Or, the maximum value
and minimum value are not 0
and they are the same.
• The I/O number for ratio con-
version is set to Not used in the
I/O specifications.
S Same as
above.
38020000 hex Ratio Set
Value Error
There is a mistake
is the ratio setting
for ratio conversion.
• A value other than 16#0000 to
16#9999 (0.00 to 99.99) was
specified for the ratio conver-
sion A constant for ratio conver-
sion.
S Same as
above.
64780000 hex Input Discon-
nection
Detected
T
he input is discon-
nected.
• Input wir
ing is broken.
• Input wiring disconnection
SU Same as
above.
64790000 hex Output Set
Value Error
The output setting
is out of range.
• An output set value setting is
out of range.
SU Same as
above.
34810000 hex Input Value
Exceeded
Adjustment
Range in
Adjustment
Mode
In Adjustment
Mode, the input
value exceeded the
range for which
adjustment is possi-
ble.
• In Adjustment Mode, the input
value exceeded the range for
which adjustment is possible,
so the offset and gain cannot
be adjusted.
US Same as
above.
34820000 hex Input Number
Specification
Error in
Adjustment
Mode
The input number
specified in Adjust-
ment Mode is not
enabled or the input
number is wrong.
• The input number that was
specified in Adjustment Mode is
not enabled.
• The setting of the Adjustment
Input Number (device variable
*_AdjCh) is incorrect, so adjust-
ment is not possible.
US Same as
above.
34880000 hex Output Num-
ber Specifi-
cation Error
in Adjustment
Mode
The output number
specified in Adjust-
ment Mode is not
enabled or the out-
put number is
wrong.
• The output number that was
specified in Adjustment Mode is
not enabled.
• The setting of the Adjustment
Output Number (device variable
*_AdjCh) is incorrect, so adjust-
ment is not possible.
US Same as
above.
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info
