Omron NJ Series Troubleshooting Manual

3 Error Tables
3-146
NJ-series Troubleshooting Manual (W503)
34AB0000 hex Basic Ether-
net Setting
Error
There is an illegal
TCP/IP setting.
• The power was interrupted dur-
ing a download.
• A communications error
occurred during a download.
S CJ-series Eth-
erNet/IP Units
Operation
Manual for NJ-
series CPU
Unit (Cat. No.
W495)
34AC0000 hex IP Address
Table Error
The IP address
table information is
incorrect.
• The power was interrupted dur-
ing a download.
• A communications error
occurred during a download.
S Same as
above.
34AD0000 hex IP Router
Table Error
The IP router table
information is incor-
rect.
• The power was interrupted dur-
ing a download.
• A communications error
occurred during a download.
S Same as
above.
34AE0000 hex Routing Table
Error
The routing table
information is incor-
rect.
• The power was interrupted dur-
ing a download.
• A communications error
occurred during a download.
S Same as
above.
34AF0000 hex Ethernet
Advanced
Setting Error
There is an illegal
FINS setting.
• The power was interrupted dur-
ing a download.
• A communications error
occurred during a download.
S Same as
above.
34B00000 hex Address Mis-
match
The host ID of the
local IP address is
inconsistent with
the FINS node
address. Or, the
last segment of the
local IP address is
inconsistent with
the setting on the
node address
switches.
• The IP address conversion
method is set to automatic gen-
eration, but the host ID of the
local IP address is inconsistent
with the FINS node address or
the last segment of the local IP
address is inconsistent with the
setting on the node address
switch.
S Same as
above.
381C0000 hex Status Area
Layout Set-
ting Error
An error occurred in
the layout setting of
the EtherNet/IP
Unit.
• There is an error in the layout
settings of the EtherNet/IP Unit.
S Same as
above.
54AE0000 hex Multiple
Switches ON
Error
More than on
e soft-
ware
switch
changed to TRUE
at the same time.
• More than one software switch
changed to TRUE at the same
time. Or, another software
switch changed to TRUE before
processing was completed for a
previous software switch.
SU Same as
above.
84E00000 hex IP Address
Duplication
Error
The same IP
address is used
more than once.
• The IP address of the Ether-
Net/IP port is also used as the
IP address of another node.
S Same as
above.
Event code Event name Meaning Assumed cause
Level
Reference
Maj Prt Min Obs Info

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
