3-155
3 Error Tables
NJ-series Troubleshooting Manual (W503)
3-2 Events in Order of Event Codes
3
3-2-2 Error Table
24010000 hex Unsupported Unit Detected Errors Related to Unit Configuration W500
24020000 hex Too Many I/O Points Errors Related to Unit Configuration W500
24030000 hex End Cover Missing Errors Related to Unit Configuration W500
24040000 hex Incorrect Unit/Expansion Rack Con-
nection
Errors Related to Unit Configuration W500
24050000 hex Duplicate Unit Number Errors Related to Unit Configuration W500
24200000 hex Slave Node Address Duplicated Built-in EtherCAT Master in CPU Unit W505
24400000 hex Unit Status, Antenna Error CJ-series ID Sensor Units Z317
24480000 hex Node Address Duplicated Error CJ-series DeviceNet Units W497
24610000 hex Switch Setting Error Block I/O (GX-series EtherCAT Slave
Units)
W488
24680000 hex Motor Non-conformity Servo G5 I576
24690000 hex Motor Non-conformity Servo G5 I576
246A0000 hex Motor Non-conformity Servo G5 I576
246B0000 hex Motor Non-conformity Servo G5 I576
246C0000 hex Motor Non-conformity Servo G5 I576
24780000 hex Number of Sensors Verify Error E3X-series Fiber Sensors with Ether-
CAT Communications Unit for Digital
Sensors
E413
24790000 hex Number of Sensors Over Limit E3X-series Fiber Sensors with Ether-
CAT Communications Unit for Digital
Sensors
E413
247A0000 hex* Number of Distributed Sensor Unit
Verify Error
EtherCAT Digital Sensor Communi-
cations Units Operation Manual
E429
247B0000 hex* Number of Sensors Over Limit EtherCAT Digital Sensor Communi-
cations Units Operation Manual
E429
247C0000 hex* Number of Sensors Verify Error EtherCAT Digital Sensor Communi-
cations Units Operation Manual
E429
247D0000 hex* Number of Sensors Over at Distrib-
uted Sensor Unit
EtherCAT Digital Sensor Communi-
cations Units Operation Manual
E429
24810000 hex* Ethernet Communications Parameter
Error
ZW-CE1@T Confocal Fiber Type Dis-
placement Sensor
Z332
24A00000 hex* Unit Configuration Error, Too Many
Units
NX-series EtherCAT Coupler Unit W519
24A10000 hex* Unit Configuration Error, Unsup-
ported Configuration
NX-series EtherCAT Coupler Unit W519
28010000 hex Motor Setting Error G5 Linear I577
28020000 hex Motor Combination Error 1 G5 Linear I577
28030000 hex Motor Combination Error 2 G5 Linear I577
30200000 hex* Unsupported Unit Setting Errors Related to Unit Configuration W500
34010000 hex I/O Setting Check Error Errors Related to Unit Configuration W500
34100000 hex IP Address Table Setting Error Errors Related to FINS Communica-
tions
W501
34110000 hex Unknown Destination Node Errors Related to FINS Communica-
tions
W501
34130000 hex FINS/TCP Connection Table Setting
Error
Errors Related to FINS Communica-
tions
W501
34200000 hex Tag Data Link Setting Error Built-in EtherNet/IP Port on CPU Unit W506
Event code Event name Functional classification Reference
