Omron NJ Series Troubleshooting Manual

3 Error Tables
3-174
NJ-series Troubleshooting Manual (W503)
64A20000 hex Tr (Receive Wait Monitoring Time)
Exceeded
CJ-series Serial Communications
Units
W494
64A30000 hex FCS Check Error CJ-series Serial Communications
Units
W494
64A40000 hex Timeout Error CJ-series Serial Communications
Units
W494
64A50000 hex Comparison Error CJ-series Serial Communications
Units
W494
64A60000 hex Reception Overflow CJ-series Serial Communications
Units
W494
64A70000 hex Command Format Error CJ-series Serial Communications
Units
W494
64AC0000 hex Send Timeout Error CJ-series DeviceNet Units W497
64CC0000 hex I/O Disconnection Detected Block I/O (GX-series EtherCAT Slave
Units)
W488
64E00000 hex Drive Prohibition Input Error 1 Servo G5 and G5 Linear I576, I577
64E10000 hex Drive Prohibition Input Error 2 Servo G5 and G5 Linear I576, I577
64E20000 hex Immediate Stop Input Error Servo G5 and G5 Linear I576, I577
64F00000 hex* Unit Over Range for Channel 1 NX-series Analog I/O Units W522
64F10000 hex* Unit Over Range for Channel 2 NX-series Analog I/O Units W522
64F20000 hex* Unit Over Range for Channel 3 NX-series Analog I/O Units W522
64F30000 hex* Unit Over Range for Channel 4 NX-series Analog I/O Units W522
64F40000 hex* Unit Over Range for Channel 5 NX-series Analog I/O Units W522
64F50000 hex* Unit Over Range for Channel 6 NX-series Analog I/O Units W522
64F60000 hex* Unit Over Range for Channel 7 NX-series Analog I/O Units W522
64F70000 hex* Unit Over Range for Channel 8 NX-series Analog I/O Units W522
64F80000 hex* Unit Under Range for Channel 1 NX-series Analog I/O Units W522
64F90000 hex* Unit Under Range for Channel 2 NX-series Analog I/O Units W522
64FA0000 hex* Unit Under Range for Channel 3 NX-series Analog I/O Units W522
64FB0000 hex* Unit Under Range for Channel 4 NX-series Analog I/O Units W522
64FC0000 hex* Unit Under Range for Channel 5 NX-series Analog I/O Units W522
64FD0000 hex* Unit Under Range for Channel 6 NX-series Analog I/O Units W522
64FE0000 hex* Unit Under Range for Channel 7 NX-series Analog I/O Units W522
64FF0000 hex* Unit Under Range for Channel 8 NX-series Analog I/O Units W522
65030000 hex* Unit I/O Disconnection Detected for
Channel 1
NX-series Analog I/O Units W522
65040000 hex* Unit I/O Disconnection Detected for
Channel 2
NX-series Analog I/O Units W522
65050000 hex* Unit I/O Disconnection Detected for
Channel 3
NX-series Analog I/O Units W522
Event code Event name Functional classification Reference

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
