Omron NJ Series Troubleshooting Manual

3
Relevant Manuals
NJ-series Troubleshooting Manual (W503)
*1 The NJ-series Troubleshooting Manual introduces the error management concepts and error items. Refer to the manuals
that are indicated with triangles for details on errors for the corresponding Units.
Testing operation and debugging
●
Using motion control ●●
Using EtherCAT ●
Using EtherNet/IP ●
Using the database connection
service
●
Using the NX Series ●●
Performing safety controls ●
Learning about error management
and corrections
*1
▲▲ ▲▲ ▲▲●▲▲ ▲
Maintenance
●
Using motion control ●●
Using EtherCAT ●
Using EtherNet/IP ●
Using the NX Series ●●
Performing safety controls ●
Using CJ-series Units ●
Purpose of use
Manual
NJ Series NX Series
Basic informa-
tion
NJ-series CPU Unit Hardware User’s Manual NJ-series CPU Unit Software User’s Manual NJ-series Instructions Reference Manual NJ-series CPU Unit Motion Control User’s Manual NJ-series CPU Unit Built-in EtherCAT Port User’s Manual NJ-series Motion Control Instructions Reference Manual NJ-series CPU Unit Built-in EtherNet/IP Port User’s Manual NJ-series Database Connection CPU Unit User’s Manual NJ-series Troubleshooting Manual NX-series EtherCAT Coupler Unit User’s Manual NX-series NX Units User’s Manuals NX-series Safety Control Unit User’s Manual NX-series Safety Control Unit Instructions Reference Manual NX-series Data Reference Manual CJ-series Special Unit Operation Manuals for NJ-series CPU Unit

Omron NJ Series Specifications

General

Program Capacity	Up to 128 MB
SD Card Slot	Yes
Power Supply Voltage	24 VDC
Motion Control	Yes
USB Ports	1
Operating Temperature	0°C to 55°C
Communication Interfaces	Ethernet/IP, EtherCAT, USB
Safety Function	Optional
Storage Temperature	-20°C to 75°C
Communication Ports	USB
Dimensions	Varies by model
Weight	Varies by model
