Omron NX-EIC202 Quick Start Guide

ConfigureOmronNX‐EIC202EtherNet/IPCouplerforUsewithRockwellAutomationPLCs 
Page3of16
1 Introduction
ThisdocumentshowsthebasicstepsforconfigurationofaRockwellAutomationPLCtoconnect
totheOMRONNX‐EIC202EtherNet/IPcoupler.Theguidewillassumethehardwareinstallation
hasalreadybeencompletedfollowing[1].
ThisdocumenthasbeenmadeusingtheAllen‐Bradley1769‐L23E‐QB1Controller,butwillapply
tootherRockwellbasedcontrollersaswell.
Thefollowingisrequired:
1. OMRONNX‐EIC202EDSfile.
2. RockwellAutomationRSLogix5000tool.
3. OMRONSysmacStudioNX‐I/Oedition.
PleasebesuretoreadtherelatedmanualstousetheNX‐EIC202Unitsafelyandproperly.
Reference Name Cat.No.
[1] NX‐SeriesEtherNet/IP CouplerUnitUser’sManual W536

Omron NX-EIC202 Specifications

General

Brand	Omron
Model	NX-EIC202
Category	Controller
Language	English
