Omron NX-ID3343 User Manual

6 Digital Input Units
6 - 10
NX-series Digital I/O Unit User’s Manual (W521)
 Sixteen-point Input Units
*1. The descriptions of Input Filter Value Setting are as follows.
*2. The descriptions of Input Filter Mode Setting are as follows.
Setting name Description
Default
value
Setting
range
Unit Index
Subin-
dex
Refer-
ence
Input Filter Value Setting Set the filter time of input
signal.
*1
*1 *1
 5000
hex
01 hex P. 6-14
Input Filter Mode Setting Set the operating mode
for the filter.
*2
*2 *2
 02 hex P. 6-14
Set
value
Setting description Default value Setting range
0 No Filter 3 0 to 11
10.25 ms
2 0.5 ms
31 ms
42 ms
54 ms
68 ms
716 ms
832 ms
964 ms
10 128 ms
11 256 ms
Set
value
Setting description Default value Setting range
0 Enable ON Filter and OFF Filter 0 0/1
1 Enable Only OFF Filter
