Omron NX-ID3343 User Manual

6 Digital Input Units
6 - 12
NX-series Digital I/O Unit User’s Manual (W521)
 Four-point Input Units
NX Units in Input Refreshing with Input Changed Time
Setting name Description
Default
value
Setting
range
Unit Index
Subin-
dex
Refer-
ence
Input Bit 00 Trigger Set-
ting
Set the trigger to read the
input changed time.
FALSE: Rising Edge
TRUE: Falling Edge
FALSE TRUE or
FALSE
 5005
hex
01 hex P. 5-21
Input Bit 01 Trigger Set-
ting
02 hex
Input Bit 02 Trigger Set-
ting
03 hex
Input Bit 03 Trigger Set-
ting
04 hex
Input Bit 00 Mode Set-
ting
Set the operation mode to
read the input changed
time.
FALSE: Continuous (Last
changed time)
TRUE: One-shot (First
changed time)
FALSE TRUE or
FALSE
 5006
hex
01 hex P. 5-21
Input Bit 01 Mode Set-
ting
02 hex
Input Bit 02 Mode Set-
ting
03 hex
Input Bit 03 Mode Set-
ting
04 hex
