A - 77
Appendices
NX-series Digital I/O Unit User’s Manual (W521)
A-3 Connecting Connector-Terminal Block
Conversion Units and I/O Relay Terminals
A
A-3-4 Connection Diagrams for I/O Relay Terminals
 G70D Relay Terminals
Note 1. Every two outputs share a common. The current
supplied is 3 A per common.
They are also isolated from the Output Unit and
I/O Relay Terminal.
“00” to “15” are the output numbers for the Output
Unit and the I/O Relay Terminal.
 G70R Relay Terminals
Note 1. All outputs are independent.
They are also isolated from the Output Unit and
I/O Relay Terminal.
“00” to “07” are the output numbers for the Output
Unit and the I/O Relay Terminal.
2. Use the G6D-4-SB short bar to short to the com-
mon terminal.
G70D-SOC16-1
Output Unit
B7
B5
B5
B3
B3
B1
NC
NC
B6
B4
B4
B2
B2
B0
0
NC
15
13
11
09
07
05
03
01
00
02
04
06
08
10
12
14
A15
A13
A11
A9
A7
A5
A3
A2
A0
A4
A6
A8
A10
A12
A1
A14
G70D
-
SOC16-1
Relay side
24
VDC
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
L
Power supply
TOP VIEW
G70R-SOC08
Output Unit
07
06
05
04
03
02
01
00
A7
A6
A5
A4
A3
A2
A1
A0
B7
B6
B5
B4
B3
B2
B1
B0
G70R
-
SOC08
24
VDC
0V
L
L
L
L
L
L
L
L
Power supply
TOP VIEW
