Omron NX Series Quick Start Guide

NX-SL/SI/SO
2
System Configuration
*OMRON CJ1W-NC@ 81/@82 Position Control Units cannot be connected to the EtherCAT Slave Terminal even though they support EtherCAT.
EtherCAT master*
NJ-series CPU Unit
Communications cable
Ethernet cables
NX Series
EtherCAT Coupler Unit
NX-ECC201/ECC202
●EtherCAT Slave Terminal
Sysmac Studio
Support Software
Sysmac Studio
Support Software
End Cover
NX Units
End Cover
NX Units
Built-in EtherCAT port
Connection to peripheral USB port
or built-in EtherNet/IP port on
NJ-series CPU Unit
Connection to peripheral USB
port on EtherCAT Coupler Unit
Peripheral USB port.
Safety CPU Unit
NX-SL3300
NX-SL3500
Safety Input Unit
NX-SID800
Safety Output Unit
NX-SOD400
Safety Input Unit
NX-SIH400
Safety Output Unit
NX-SOH200
NX Series
EtherCAT Coupler Unit
NX-ECC201

Omron NX Series Specifications

General

Programming Languages	Ladder, Structured Text, Function Block Diagram, Sequential Function Chart
Communication Ports	Ethernet, USB, RS-232C, RS-485
Memory Capacity	Varies by model
Program Memory	Varies by model
Data Memory	Varies by model
Operating Temperature	0°C to 55°C
Power Supply	24 VDC
Ethernet Ports	1 or 2 ports (depending on model)
USB Ports	1 or 2 ports (depending on model)
Dimensions	Varies by model
Weight	Varies by model
