Omron NX-SL3300 - Page 421

TS in-
dica-
tor
NS In-
dica-
tor
FS in-
dica-
tor
P ERR In-
dicator
Sev-
en-
seg-
ment
Indi-
cator
Cause Corrective action
--- --- --- --- Non-volatile Memory Access
Error
Refer to Non-volatile Memory
Access Error ( page
12 - 57).
--- --- ---
--- Division by Zero Refer to Division by Zero
( page 12 - 53).
---
--- ---
--- Cast Error Refer to Cast Error ( page
12 - 54).
--- --- --- --- MUX Error Refer to MUX Error ( page
12 - 55).
--- --- ---
1-second
interval
--- SF_Antivalent Error Refer to SF_Antivalent Error
( page 12 - 44).
---
--- ---
1-second
interval
--- SF_EDM Error Refer to SF_EDM Error
( page 12 - 44).
---
--- ---
1-second
interval
--- SF_EmergencyStop Error Refer to SF_EmergencyStop
Error ( page 12 - 45).
---
--- ---
1-second
interval
--- SF_EnableSwitch Error Refer to SF_EnableSwitch
Error ( page 12 - 45).
--- --- ---
1-second
interval
--- SF_Equivalent Error Refer to SF_Equivalent Error
( page 12 - 46).
---
--- ---
1-second
interval
--- SF_ESPE Error Refer to SF_ESPE Error
( page 12 - 46).
---
--- ---
1-second
interval
--- SF_GuardLocking Error Refer to SF_GuardLocking
Error ( page 12 - 47).
---
--- ---
1-second
interval
--- SF_GuardMonitoring Error Refer to SF_GuardMonitoring
Error ( page 12 - 47).
---
--- ---
1-second
interval
--- SF_ModeSelector Error Refer to SF_ModeSelector
Error ( page 12 - 48).
---
--- ---
1-second
interval
--- SF_MutingPar Error Refer to SF_MutingPar Error
( page 12 - 48).
