Appendices

A - 82

G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications

1B01 hex 258th transmit PDO

Mapping

–––––––

00 hex Number of objects in

this PDO

09 hex – – 1 byte

(U8)

RO Not

possible

–

01 hex 1st Input Object to be

mapped

603F 0010 hex – – 4 bytes

(U32)

RO Not

possible

–

02 hex 2nd Input Object to be

mapped

6041 0010 hex

– – 4 bytes

(U32)

RO Not

possible

–

03 hex 3rd Input Object to be

mapped

6064 0020 hex

– – 4 bytes

(U32)

RO Not

possible

–

04 hex 4th Input Object to be

mapped

6077 0010 hex

– – 4 bytes

(U32)

RO Not

possible

–

05 hex 5th Input Object to be

mapped

60F4 0020 hex – – 4 bytes

(U32)

RO Not

possible

–

06 hex 6th Input Object to be

mapped

60B9 0010 hex – – 4 bytes

(U32)

RO Not

possible

–

07 hex 7th Input Object to be

mapped

60BA 0020 hex

– – 4 bytes

(U32)

RO Not

possible

–

08 hex 8th Input Object to be

mapped

60BC 0020 hex

– – 4 bytes

(U32)

RO Not

possible

–

09 hex 9th Input Object to be

mapped

60FD 0020 hex

– – 4 bytes

(U32)

RO Not

possible

–

1B02 hex 259th transmit PDO

Mapping

–––––––

00 hex Number of objects in

this PDO

09 hex – – 1 byte

(U8)

RO Not

possible

–

01 hex 1st Input Object to be

mapped

603F 0010 hex – – 4 bytes

(U32)

RO Not

possible

–

02 hex 2nd Input Object to be

mapped

6041 0010 hex

– – 4 bytes

(U32)

RO Not

possible

–

03 hex 3rd Input Object to be

mapped

6064 0020 hex

– – 4 bytes

(U32)

RO Not

possible

–

04 hex 4th Input Object to be

mapped

6077 0010 hex

– – 4 bytes

(U32)

RO Not

possible

–

05 hex 5th Input Object to be

mapped

60610008 hex

– – 4 bytes

(U32)

RO Not

possible

–

06 hex 6th Input Object to be

mapped

60B9 0010 hex – – 4 bytes

(U32)

RO Not

possible

–

07 hex 7th Input Object to be

mapped

60BA 0020 hex – – 4 bytes

(U32)

RO Not

possible

–

08 hex 8th Input Object to be

mapped

60BC 0020 hex

– – 4 bytes

(U32)

RO Not

possible

–

09 hex 9th Input Object to be

mapped

60FD 0020 hex – – 4 bytes

(U32)

RO Not

possible

–

Index

Sub-

Index

Name

Default

setting

Setting range Unit Size

Data

attribute

PDO

map

Corresponding

Pn number
