A - 115
Appendices
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
A-3 Sysmac Error Status Codes
A
A-3-2 Error Description
Event name IPM Error Event code 04AD 0000 hex
Description The current flowing through the converter exceeded the specified value.
Source
EtherCAT Master Function Module
Source
details
Slave Detection
timing
Continuously
Error
attributes
Level
Minor fault
Recovery
Error reset
(after cycling slave
power)
Log category
System
Effects User program Continues. Operation Power drive circuit is OFF for relevant slave.
Indicators
EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
–––
System
-defined
variables
Variable Data type Name
None – –
Cause and
correction
Assumed cause Correction Prevention
A short-circuit, line-to-ground
fault, contact failure, or insulation
failure occurred on the U, V, or W
motor line.
If there is a short-circuit,
line-to-ground fault, or contact
failure on the U, V, or W motor line,
correct the connections. If the
insulation resistance between the
U, V, or W motor line and the
ground line has failed, replace the
motor.
Confirm that the U, V, and W
motor lines are connected
correctly.
The Servo Drive failed. Disconnect the motor lines and
turn ON the Servo. If this error
occurs immediately, replace the
Servo Drive.
None
The relay for the dynamic brake
has been welded due to frequent
servo ON/OFF operations.
Replace the Servo Drive. Do not start and stop operation by
frequently switching the Servo
ON/OFF.
Motor windings are burned out. Check the balance of the
resistance between the lines of the
motor. If resistance is unbalanced,
replace the motor.
Do not apply excessive load on
the motor.
The motor is not suitable for the
Servo Drive.
Check the model (capacity) of the
motor and the Servo Drive on the
nameplates. Replace the motor
with a motor that matches the
Servo Drive.
Use a motor that matches the
Servo Drive.
The command input timing is the
same as or earlier than the servo
ON timing.
Wait at least 100 ms after the
servo has been turned ON, then
input commands.
Wait at least 100 ms after the
servo has been turned ON, then
input commands.
Attached
information
None
Precautions/
Remarks
“14” is displayed on the Servo Drive front panel and F114 is given as the AlarmCode (4001 hex).
