Omron R88D-KN10F-ECT-L User Manual

Appendices
A - 160
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
Event name External Encoder Error Warning Event code 0806 0000 hex
Description The external encoder detected a warning.
Source
EtherCAT Master Function Module
Source
details
Slave Detection
timing
Continuously
Error
attributes
Level
Observation
Recovery
–
Log category
System
Effects User program Continues. Operation Not affected.
Indicators
EtherNet/IP NET RUN EtherNet/IP NET ERR EtherNet/IP LINK/ACT
–––
System
-defined
variables
Variable Data type Name
None – –
Cause and
correction
Assumed cause Correction Prevention
There is insufficient external
encoder power supply voltage.
Provide the required external
encoder power supply voltage 5
VDC ±5% (4.75 to 5.25 V).
Provide the required external
encoder power supply voltage 5
VDC ±5% (4.75 to 5.25 V).
Noise is entering on the external
encoder connector cable.
If the motor cable and the external
encoder cable are bundled
together, separate them. Connect
the shield to FG.
If the motor cable and the external
encoder cable are bundled
together, separate them. Connect
the shield to FG.
The external encoder failed. If none of the above causes
applies, replace the external
encoder.
None
Attached
information
None
Precautions/
Remarks
“A8” is displayed on the front panel of the Servo Drive.
