Appendices
A - 98
G5-series Linear Motors/Servo Drives With Built-in EtherCAT Communications
0810 0000
hex
External
Encoder
Status Error 2
Bit 02 of the external
encoder error code
(ALMC) was set to 1.
Bit 02 of the external encoder
error code (ALMC) was set to
1.
3 P.A-120
0811 0000
hex
External
Encoder
Status Error 3
Bit 03 of the external
encoder error code
(ALMC) was set to 1.
Bit 03 of the external encoder
error code (ALMC) was set to
1.
3 P.A-120
0812 0000
hex
External
Encoder
Status Error 4
Bit 04 of the external
encoder error code
(ALMC) was set to 1.
Bit 04 of the external encoder
error code (ALMC) was set to
1.
3 P.A-121
0813 0000
hex
External
Encoder
Status Error 5
Bit 05 of the external
encoder error code
(ALMC) was set to 1.
Bit 05 of the external encoder
error code (ALMC) was set to
1.
3 P.A-121
0814 0000
hex
Phase-A
Connection
Error
An error such as
broken wiring was
detected in the
external encoder
phase-A connection.
An error such as broken
wiring was detected in the
external encoder phase-A
connection.
3 P.A-122
0815 0000
hex
Phase-B
Connection
Error
An error such as
broken wiring was
detected in the
external encoder
phase-B connection.
An error such as broken
wiring was detected in the
external encoder phase-B
connection.
3 P.A-122
0816 0000
hex
Phase-Z
Connection
Error
An error such as
broken wiring was
detected in the
external encoder
phase-Z connection.
An error such as broken
wiring was detected in the
external encoder phase-Z
connection.
3 P.A-123
14A8 0000
hex
Object Error The object area data
in non-volatile
memory is corrupted.
• Noise
• Non-volatile memory
failure
3 P.A-123
14A9 0000
hex
Object Error The object area data
in non-volatile
memory is corrupted.
• Noise
• Non-volatile memory
failure
3 P.A-124
14AA 0000
hex
3 P.A-124
14AB 0000
hex
Object
Corrupted
The checksum data in
non-volatile memory is
corrupted.
Non-volatile memory failure 3 P.A-125
14AC 0000
hex
3 P.A-125
14AD 0000
hex
3 P.A-126
2801 0000
hex
Motor Setting
Error
Settings associated
with the motor and
external encoder are
missing.
Settings associated with the
motor and external encoder
are missing.
3 P.A-126
2802 0000
hex
Motor
Combination
Error 1
The value set for the
motor current exceeds
the maximum motor
capacity allowed for
the Servo Drive.
The Motor Rated Rms
Current/Motor Peak Absolute
Current exceeds the
maximum motor capacity
allowed for the Servo Drive.
3 P.A-127
Event
code
Event name Description Assumed cause
Level
Reference
Maj Prt Min Obs Info
