Omron S82K

S82K
S82K
15
 ACCESSORIES
Unit: mm (inch)
DIN Rail Mounting Track (Order Separately)
4.5
15 25 25 25 25
10 10
1,000 (500)
(See Note.)
7.3
35
27
1
4.5
15 25 25 25 25 15
10 10
1,000
35
27 24
16
29.2
1 1.5
PFP-100N2
15 (5)
(See Note.)
Note: The values shown in parentheses are for the PFP-50N.
12, 25 x 4.5 oblong
Noise Filter (Order Separately)
39
16 max.
A
B
Two, 4.8 dia.
(Mounting
holes)
D
6.5
4
Six, M4
6.5
C
16 max.
4
Nameplate
47
PFP-100N/PFP-50N
S82Y-JF3-N for 3- to 50-W models
S82Y-JF6-N for 90-W and 100-W Models
Model
A B C D
S82Y-JF3-N 107 (4.21) 75 (2.95) 90 (3.54) 26 (1.02)
S82Y-JF6-N 117 (4.60) 85 (3.35) 100 (3.93) 30 (1.18)
