Omron S8VS-01505

S8VS
22
Note: The illustration shows the S8VS-24024A model.
Note: The illustration shows the S8VS-48024A model.
Power Supplies with Screwless Terminal Blocks
Note: The illustration shows the S8VS-06024-F model.
Note: The illustration shows the S8VS-12024-F model.
7
125.2
117.6
35.4
10
50
94
100
115
Seven, M4 terminal screws
with square washers
Rail stopper
4.5 (Sliding: 15 max.)
Rail stopper
7.6
1
Screwless block (2.5-mm pitches)
S8VS-24024 (240 W)
S8VS-24024A@ (240 W)
S8VS-24024B@ (240 W)
S8VS-24024BE (240 W)
S8VS-48024 (480 W)
S8VS-48024A (480 W)
S8VS-48024B (480 W)
10
70
Rail stopper
Nine, M4 terminal screws with square washers
4.5 (Sliding: 15 max.)
Rail stopper
123.8
127.2
35.4
93
115
115
150
Screwless block (2.5-mm pitches)
7
10
107.3
1
97.1
10.2
35.4
9577.4
40
4.5 (Sliding: 15 max.)
Rail stopper
S8VS-06024-F (60 W)
S8VS-06024A-F (60 W)
S8VS-06024B-F (60 W)
10
50
10
120.3
110.3
1
115
35.4 97.3
4.5 (Sliding: 15 max.)
Rail stopper
S8VS-09024-F (90 W) /S8VS-09024S-F (90 W) /S8VS-12024-F (120 W)
S8VS-09024A@-F (90 W) /S8VS-09024A@S-F (90 W ) /S8VS-12024A@-F (120 W)
S8VS-09024B@-F (90 W) /S8VS-09024B@S-F (90 W) /S8VS-12024B@-F (120 W)
S8VS-09024BE-F (90 W) /S8VS-09024BES-F (90 W) /S8VS-12024BE-F (120 W)
