Omron S8VS-06024

S8VS
21
Dimensions
Power Supplies with Screw Terminal Blocks
Note: All units are in millimeters unless otherwise indicated.
Note: The illustration is the S8VS-03024 model.
Note: The illustration is the S8VS-06024A model.
Note: The illustration is the S8VS-12024A model.
Note: The illustration is the S8VS-18024A model.
Rail Stopper
4.8
(Sliding: 10 max.)
4.8
(Sliding: 10 max.)
4
10.2
10.4
Five, M3.5 Square Washer Screw
8
35.2
96.4
±1
85±1
22.5±1
S8VS-015@@ (15 W)
S8VS-030@@ (30 W)
7
1
10
97.1 12 max.
103.3
4.5
(Sliding: 15 max.)
Five, M4 Square
Washer Screw
Rail Stopper
35.4 74 95
±1
40±1
S8VS-06024 (60 W)
S8VS-06024A (60 W)
S8VS-06024B (60 W)
1
7
10
110.3 11 max.
116.2
Five, M4 Square
Washer Screw
4.5
(Sliding: 15 max.)
Screw Lessly Terminal
(The 2.5 mm pace)
35.4
94 115
±1
50 ±1
Rail Stopper
S8VS-09024 (90 W) /S8VS-09024S (90 W) /S8VS-12024 (120 W)
S8VS-09024A@ (90 W) /S8VS-09024A@S (90 W) /S8VS-12024A@ (120 W)
S8VS-09024B@ (90 W) /S8VS-09024B@S (90 W) /S8VS-12024B@ (120 W)
S8VS-09024BE (90 W) /S8VS-09024BES (90 W) /S8VS-12024BE (120 W)
1
7
94
10
75
±1
116.6 9 max.
120.3
35.4
Rail StopperScrew Lessly Terminal
(The 2.5 mm pace)
4.5
(Sliding: 15 max.)
115
±1
Seven, M4 Square
Washer Screw
S8VS-18024 (180 W)
S8VS-18024A@ (180 W)
S8VS-18024B@ (180 W)
S8VS-18024BE (180 W)
