Omron S8VS-06024

S8VS
9
AC (L)
INPUT
AC (N)
DC OUTPUT
+V
−V
Voltage
detection circuit
Photocoupler
Rectifier/smoothing circuit
Rectifier/smoothing circuit
Rectifier/
smoothing
circuit
Noise filter
Drive control
circuit
Fuse
6.3 A
Overcurrent
circuit
Current detection
circuit
Arithmetic
operation circuit
Display circuit
Switch
Overvoltage
detection circuit
Inrush
current
protection
circuit
Rectifier
S8VS-06024A-@ (60 W)
S8VS-06024B-@ (60 W)
S8VS-06024-@ (60 W)
AC (L)
INPUT
AC (N)
+V
−V
DC OUTPUT
Fuse
6.3 A
Rectifier
Voltage
detection circuit
Photocoupler
Rectifier/smoothing circuit
Noise filter
Drive control
circuit
Overcurrent
circuit
Current detection
circuit
Overvoltage
detection circuit
Inrush current
protection
circuit
Smooth-
ing
circuit
