SmartStep 2 servo drive 99
AC Servo systems
Computer cable (for CN3)
Filter
External regenerative resistor
Connectors
Computer software
K
Position control unit connecting cable CQM1H-PLB21 0.5 m XW2Z-050J-A3
1 m XW2Z-100J-A3
CS1W-NC113 or C200HW-NC113 0.5 m XW2Z-050J-A6
1 m XW2Z-100J-A6
CS1W-NC213/413 or C200HW-NC213/413 0.5 m XW2Z-050J-A7
1 m XW2Z-100J-A7
CS1W-NC133 0.5 m XW2Z-050J-A10
1 m XW2Z-100J-A10
CS1W-NC233/433 0.5 m XW2Z-050J-A11
1 m XW2Z-100J-A11
CJ1W-NC113 0.5 m XW2Z-050J-A14
1 m XW2Z-100J-A14
CJ1W-NC213/413 0.5 m XW2Z-050J-A15
1 m XW2Z-100J-A15
CJ1W-NC133 0.5 m XW2Z-050J-A18
1 m XW2Z-100J-A18
CJ1W-NC233/433 0.5 m XW2Z-050J-A19
1 m XW2Z-100J-A19
CJ1M-CPU21/22/23 0.5 m XW2Z-050J-A33
1 m XW2Z-100J-A33
L
General purpose cable For general purpose controllers 1 m R88A-CPG001S
2 m R88A-CPG002S
M
Terminal block cable For general purpose controllers 1 m XW2Z-100J-B24
2 m XW2Z-200J-B24
N
Terminal block (M3 screw and for pin terminals) - XW2B-50G4
Terminal block (M3.5 screw and for fork/round terminals) - XW2B-50G5
Terminal block (M3 screw and for fork/found terminals) - XW2D-50G6
Symbol Description Connect to Model
Symbol Name Model
O
Computer cable RS232 2 m R88A-CCG002P2
Symbol Applicable
servodrive
Filter model Rated
current
Leak-
age
current
Rated
voltage
P
R88D-GP08H R88A-FIK107-RE 6.6 A 3.5 mA 250 VAC
single-
phase
Symbol Regenerative resistor unit model Specifications
Q
R88A-RR08050S 50 Ω, 80 W
R88A-RR080100S 100 Ω, 80 W
R88A-RR22047S 47 Ω,220 W
R88A-RR50020S 20 Ω, 500 W
Specifications Model
I/O connector kit -50 pins- (for CN1) R88A-CNU11C
Power cable connector (motor side) R88A-CNG01A
Encoder connector (Servo drive side CN2) R88A-CNW01R
Incremental encoder cable connector (motor side) R88A-CNG02R
Specifications Model
Configuration and monitoring software tool for servo drives
and inverters (CX-drive version 1.91 or higher).
CX-Drive
