2–3 Dimensions and Installation
This section gives dimensions and other information necessary for mounting
the CPUs, Expansion I/O Units, Analog Timer Units, and I/O Link Units. All
measurements are in mm.
CPUs (The C20K is shown as an example.)
A
240
240
290
340
Model
C20K
C28K
C40K
C60K
B
250
250
300
350
C
100
100
100
120
Four M4 screws
D
110
110
110
140
E
5
5
5
15
Expansion I/O Units (The C20P is shown as an example.)
Four M4 screws
Dimensions and Installation Section 2–3
