18
When
only one Expansion I/O Rack is required, a
simplified system configura
-
tion
may be used. The CPU Backplane can be connected directly to the Expan
-
sion
I/O Backplane without the use of the I/O Control and I/O Interface Units.
T
er-
mination Resistance Units are also not required.
All Units except for CPU Bus Units (Temperature Controller Data Link Units,
SYSMAC NET Link Units, SYSMAC LINK Units, SYSMAC BUS/2 Masters,
Ethernet
Units, Personal Computer Units, and BASIC Units) can be mounted to
any
of the Backplanes for which they listed in the following diagram. CPU
Bus
Units can be mounted to any slot on any CPU Backplane except for the
CVM1-BC053 or CVM1-BC103 Backplane, on which CPU Bus Units can be
mounted only to the rightmost 3 and 6 slots, respectively.
I/O
Connecting Cable
CV500-CNjj3
I/O Backplane
CV500-BI042/062/1
12 or
CVM1-BI064/114
Power Supply Unit
CV500-PS221/PS211
or CVM1-P
A208
4/6/11 slots
C500 I/O Units
C500 Special I/O Units
SYSMAC BUS Masters
CPU Backplane: CV500-BC031/051/101 or
CVM1-BC053/103
Power Supply Unit: CV500-PS221/PS21
1 or
CVM1-PA208
CPU: CV500-CPU01-EV1, CV1000-CPU01-EV1,
CV2000-CPU01-EV1, CVM1-CPU01-EV2,
CVM1-CPU1
1-EV2, or CVM1-CPU21-EV2
3, 5, or 10 slots
SYSMAC NET Link Units
SYSMAC LINK Units
SYSMAC BUS/2 Masters
Personal Computer Units
BASIC Units
C500 I/O Units
C500 Special I/O Units
SYSMAC BUS Masters
Systems with a Single
Expansion I/O Rack
System Configuration Section 2-1
