10
Section 1
1.2 Features
V700-L21
User's Manual
Section 1
System Configuration and Features
● Model V700-HMD13 , or V700-HMD11-1 (ID R/W head)
An ID R/W head reads or writes data from or into the memory on ID tag without a need to contact the
ID tag. It will be hereunder simply called IDRW head (or, more simply, IDRWH). It is operated as linked
to the CIDRW controller via a link unit.
Two differently formed IDRW head types are available:
➀
Model V700-HMD13 features a form and data transaction performance suitable for the "undocked
position" per SEMI standards.
➁
Model V700-HMD11-1 features a form and data transaction performance suitable for the "docked
position" per SEMI standards. It is delivered together with two mounting nuts.
● Model V700-D23P41 (ID tag)
This is a round rod type ID tag that measures 3.9 mm in diameter and 25 mm in length. It contains a
memory space of 240 bytes that allows a user to read or write data from or into it.
Mounting nut (2 M4)
To Next Page
