Omron Z - Basic Models (Drip-proof) with Terminal Protective Cover

F-182 General-purpose Basic Switch Z
Basic Models (Drip-proof) with Terminal Protective Cover
Note: Do not use the M12 mounting screw and the case mounting hole at the same time, or the case may be damaged.
Note: Do not use the M12 mounting screw and the case mounting hole at the same time, or the case may be damaged.
OF max.
RF min.
PT max.
OT min.
MD max.
2.45 to 4.22 N
{250 to 431 gf}
1.12 N {114 gf}
2.2 mm
0.13 mm
0.06 mm
OP 15.9±0.4 mm
OF max.
RF min.
PT max.
OT min.
MD max.
5.30 N {541 gf}
1.12 N {114 gf}
2.4 mm
3.5 mm
0.06 mm
OP 37.8±1.2 mm
OF max.
RF min.
PT max.
OT min.
MD max.
5.30 N {541 gf}
1.12 N {114 gf}
1.8 mm
5.5 mm
0.06 mm
OP 21.8±0.8 mm
OF max.
RF min.
PT max.
OT min.
MD max.
5.30 N {541 gf}
1.12 N {114 gf}
1.8 mm
3.58 mm
0.06 mm
OP 33.4±1.2 mm
Pin Plunger
Z-15GA55-B5V
6SR (stainless-steel plunger)
4.2
+0.075
dia. hole
−0.025
3.9 dia.
4.36
+0.1
dia.
−0.05
Z-15GK3A55-B5V
11.9SR (stainless-steel plunger)
4.2
+0.075
dia. hole
−0.025
17 dia.
8.35 dia.
4.36
+0.1
dia.
−0.05
Panel Mount Plunger
Z-15GQA55-B5V
11.9SR (stainless-steel plunger)
4.2
+0.075
dia. hole
−0.025
4.36
+0.1
dia.
−0.05
8.35 dia.
16 dia.
Two hexagonal
nuts (2 t × 14
width across fla
t
Two lock nuts
(2 t × 15.6
width across
flats)
Panel Mount Roller Plunger
Z-15GQ22A55-B5V
4.2
+0.075
dia. hole
−0.025
4.36
+0.1
dia.
−0.05
16 dia.
Two hexagonal nuts
(3 t
×
17 width
across flats)
12.7 dia.
×
4.8
(stainless-steel roller)
