OMS ARCADIA EXT - 3.2. Foot Control Operation

OMS ARCADIA EXT S.T.01/3R ED.0 REV.8 09/2020
21
3.2. CHAIR COMMAND FROM FOOTCONTROL
The footcontrol has two side levers (B and C) that allow the operator to position the chair using the controls on
the foot:
Ascent command pantograph;
Descent command pantograph;
Ascent backrest command;
Descent backrest command.
