4.2. DOUBLE JOINT HEADREST WITH CLICK
The double joint headrest with Click is adjustable in height with an excursion of about 23 cm and has two
articulations simultaneously commandable using the lever placed in the rear; it makes it easy to move the
headrest on two rotation axes.
By carrying the headboard cushion to an inclination of about 90 ° with respect to the swivel mechanism, it can
be rotated on itself by 180 °. It is also possible to lower the joint mechanism in a position that gives the
headrest greater comfort for patients of modest stature.
Note:
Once the headrest is positioned in the working position, reposition the release lever in place to
lock the movement.
