OMS ARCADIA EXT S.T.01/3R ED.0 REV.8 09/2020
41
3. Position the patient chair side by side with the unit so that the bases on the short edge are
aligned in the rear and so that the bases on the long side are perfectly parallel. The plate
protruding to the left of the base of the chair must be positioned as in the picture.
DANGER
